GAE Graphics Software Products and DISSPLA Compatibility

Galaxy Advanced Engineering, Inc. presents a migration bridge for callable CA-DISSPLA (Display Integrated Software System & Plotting Language) routines within your existing FORTRAN program via its high level FORTRAN graphics library Language that is called UGL. UGL is a Scientific Graphics Subroutine Library for any computing system such as Main, Micro and Mini-Computers with its given Operating System. UGL presently supports hardware such as HP/UX, SUN/SOLARIS, Alpha/OpenVMS, VAX/VMS, LINUX, SGI/IRIX and Windows 95/98/2000 and NT or DOS

UGL-GRAPHICS was developed to provide a migration path with a GKS, PLOT10, PLOT88, CalComp and DIGLIB (from Lawrence Livermore Lab.) graphics interface in the PC and VAX as well as UNIX environment and provides the same high graphics standards found on the main frames using the above graphics libraries. The most common subset of CA-DISSPLA routine (more than %95) and rest of the mentioned graphics libraries are supported directly and any particular ones may be provided upon request. If the users have an existing code using any of these graphics library routines within them, they do not have to change their calls. The bridge that are built with UGL-GRAPHICS library of Galaxy Advanced Engineering, Inc. will distinguish these routines and maps them to its own routine against these calls for direct porting of the user code to its new environment supported by UGL-GRAPHICS.

What is DISSPLA?

CA-DISSPLA is a powerful library of FORTRAN subroutines that facilitate data plotting. It was designed for engineers, economists, statisticians, and scientific and bussiness programmers. This package originally was developed by a company named ISCO prior to being sold to Computer Associate. Presently the CA-DISSPLA is owned by Computer Associate. The following are the most famous graphics examples of DISSPLA that are drawn via UGL, which is representing capability of UGL and illustrate same power as CA-DISSPLA.
